Swiwin Turbine SW220B 22Kg Thrust Jet Engine

Swiwin Turbine SW220B 22Kg Thrust Jet Engine

The Swiwin SW220B is a compact, high-performance miniature turbine engine designed for serious RC jet modelers, turbine aircraft builders, advanced aeromodelling pilots and professional aircraft propulsion projects. Delivering 22kg / 220N thrust, the SW220B combines strong power output, fast response, brushless starter technology, telemetry support and auto-restart functionality for demanding jet-model applications.

KEY FEATURES & BENEFITS:

• High-Performance 22Kg Turbine Platform:
• • 22kg / 220N thrust class turbine engine
• • Speed range from 38,000 to 115,000 RPM
• • Compact and lightweight turbine design
• • 1740g engine weight reference
• • 115.5mm diameter and 278.5mm length reference
• • Suitable for large RC jet aircraft and professional turbine model applications

• Modern Turbine Control System:
• • 32-bit ECU control system
• • Brushless starter for stable output and long service life
• • Brushless fuel pump support
• • Telemetry functions for real-time turbine data monitoring
• • Color screen data terminal / GSU support
• • Auto-start and auto-restart turbine operation
• • CNC compressor wheel for smooth operation and strong output

• Professional Jet Model Integration:
• • Aviation kerosene fuel compatibility
• • 3%–5% lubrication reference
• • Rated exhaust maximum temperature reference of 750°C
• • Fuel consumption reference of ≤620g/min
• • 25-hour maintenance cycle
• • Designed for performance, dependability and demanding turbine aircraft setups
• • Installation and operation should be handled by trained turbine operators only

APPLICATIONS: RC jet aircraft, scale turbine jet models, large high-performance aeromodelling aircraft, turbine aircraft propulsion projects, jet trainer models, sport jet models, professional RC turbine workshops, engineering college propulsion labs, turbine engine demonstration platforms, aeromodelling clubs, advanced aircraft power-system integration, controlled turbine testing and maintenance training.

FREQUENTLY ASKED QUESTIONS:

• Q: What is the Swiwin SW220B turbine?
• A: The Swiwin SW220B is a miniature turbine jet engine for large RC jet aircraft and model aircraft propulsion projects, rated at 22kg / 220N thrust.

Q: What is the price of the Swiwin SW220B turbine? A: The listed import price is 6,75,000 ₹ for the Swiwin SW220B 22Kg Turbine Standard Package. Final pricing may vary if installation support, telemetry setup, fuel-system planning, workshop support or propulsion test support is added.

• Q: What thrust does the Swiwin SW220B produce?
• A: The listed thrust is 22kg / 220N.

• Q: What is the RPM range?
• A: The listed speed range is 38,000–115,000 RPM.

• Q: What is the idle RPM?
• A: The listed idle RPM is 38,000 RPM.

• Q: What are the dimensions of the SW220B?
• A: The listed turbine diameter is 115.5mm and the listed length is 278.5mm.

• Q: What is the weight of the Swiwin SW220B?
• A: The listed engine weight is 1740g.

• Q: What is the rated exhaust temperature?
• A: The listed rated exhaust maximum temperature is 750°C. Turbine exhaust is extremely hot and requires strict safety management.

• Q: What fuel does the Swiwin SW220B use?
• A: The listed fuel is aviation kerosene. Fuel quality and oil percentage should follow the turbine manual and local fuel availability.

• Q: What lubrication percentage is required?
• A: The listed lubrication reference is 3%–5%. Use suitable turbine oil according to manual guidance.

• Q: What is the fuel consumption?
• A: The listed fuel consumption reference is ≤620g/min. Actual fuel consumption depends on RPM, throttle profile, air density and operating conditions.

• Q: Does the SW220B have auto-start?
• A: Yes, the SW220B is listed with full auto-start support.

• Q: Does the SW220B have auto-restart?
• A: Yes, the SW220B supports auto-restart functionality.

• Q: Does it include telemetry?
• A: Yes, the SW220B supports telemetry functions for monitoring turbine operating data.

• Q: What starter system does it use?
• A: The SW220B uses a brushless starter.

• Q: What fuel pump does it use?
• A: The product references a brushless fuel pump.

• Q: What ECU does it use?
• A: The product references a 32-bit ECU / ECU V3 control system.

• Q: What is the maintenance interval?
• A: The listed maintenance cycle is 25 hours.

• Q: Is this turbine suitable for beginners?
• A: No. The SW220B is an advanced turbine engine intended for trained turbine operators, experienced RC jet pilots and professional workshops.

• Q: What aircraft is the SW220B suitable for?
• A: It is suitable for compatible large RC jet aircraft, scale turbine models, sport jets and controlled turbine propulsion test platforms.

Q: Is the SW220B suitable for UAV prototypes? A: It may be evaluated in lawful aircraft propulsion research or prototype projects only if the airframe, fuel system, ECU, thermal safety, failsafe design, field safety and aviation compliance requirements are professionally engineered.

Q: What else is required for installation? A: Typical required items include compatible airframe mount, turbine fuel tank, fuel tubing, suitable battery, receiver interface, ECU/GSU setup, fuel filter, fuel valve, heat shielding, fire extinguisher, ground support tools and safe test-area equipment.

Q: What safety precautions are important? A: Operators must follow turbine fire safety, fuel safety, hot-exhaust safety, intake safety, hearing protection, failsafe checks, controlled startup, controlled shutdown and field rules. Never operate the turbine near loose objects, people, dry grass or flammable materials.

• Q: Why is FOD prevention important?
• A: Foreign object debris can damage the compressor and turbine section. Keep the intake area clean and secure all loose items before starting the turbine.

Q: What maintenance is required? A: Maintenance should include checking fuel filters, fuel lines, ECU data, pump function, starter function, battery health, turbine mounts, intake cleanliness, exhaust area, telemetry readings and scheduled service at the listed maintenance interval.

Q: What warranty is included? A: Warranty support generally covers manufacturing defects under approved use and normal operating conditions. Damage from FOD ingestion, bad fuel, incorrect oil mix, overheating, crash impact, improper ECU setup, fuel-system contamination, water exposure, unauthorized modification or unsafe operation may not be covered.
