FlySpark HD-2 Portable Anti-Drone System | Detection • Tracking • Laser Intercept

FlySpark HD-2 Portable Anti-Drone System - Detection • Tracking • Laser Intercept

The FlySpark HD-2 is a rapidly deployable portable counter-UAS system designed for authorized protection against consumer drone threats. Built around a stabilized gimbal head and rugged tripod platform, HD-2 combines detection, identification, tracking and laser interception into a compact all-in-one architecture that can be deployed by a trained single operator in under one minute.

KEY FEATURES & BENEFITS:

• All-in-One Portable C-UAS Platform:
• • Combines drone detection, identification, tracking and laser interception
• • Designed for consumer drone threat mitigation in authorized security environments
• • Stabilized gimbal head with rugged tripod deployment
• • Single-person portable configuration for rapid field readiness
• • Supports fixed-site, tripod and vehicle-mounted deployment modes

• High-Accuracy Tracking & Intercept Support:
• • Detection range of 200–1000 m under stated visibility and RCS conditions
• • Intercept distance of 200–600 m under stated visibility and RCS conditions
• • Tracking accuracy below 10 μrad RMS
• • Intercept time ≤20 seconds depending on target conditions and operator workflow
• • Laser output power ≤1.4 kW with strict laser-safety compliance requirement

• Intelligent Control Interface:
• • Visual control terminal with 9″ or 15″ screen options
• • Wired bidirectional communication support
• • Interface can show target status, battery status, intercepted image and target distance
• • Optional automatic unmanned control available depending on approved configuration
• • Suitable for airports, power stations, factories, train stations, events, important places and intelligent city low-altitude security networks

AUTHORIZED USE ONLY: The FlySpark HD-2 is a restricted counter-UAS and laser-interception security system intended only for authorized government agencies, defence organizations, law-enforcement bodies, airport security teams, critical infrastructure operators, approved security agencies and licensed entities. Procurement and deployment may require KYC, end-use documentation, site approval, aviation permissions, laser-safety controls, operator training, risk assessment and applicable legal authorization. Unauthorized civilian use, unsafe laser operation, unlawful interception or unapproved deployment is strictly not permitted.

FREQUENTLY ASKED QUESTIONS:

Q: What is the FlySpark HD-2 Portable Anti-Drone System? A: The FlySpark HD-2 is a portable counter-UAS system for consumer drone threats. It combines detection, identification, tracking and laser interception in a stabilized gimbal head with rugged tripod deployment.

Q: What is the price of the FlySpark HD-2? A: The listed import price is 13,00,00,000 ₹ for the HD-2 Portable Anti-Drone Standard Package. Final pricing may vary depending on fixed installation, vehicle mounting, training, deployment planning, maintenance support and custom security integration.

Q: What functions does HD-2 include? A: HD-2 supports drone detection, identification, tracking and laser interception. It is designed as an all-in-one portable C-UAS response platform for authorized security users.

• Q: What type of drone threat is HD-2 designed for?
• A: HD-2 is designed for consumer drone threats. Performance depends on drone size, RCS, visibility, background conditions, weather and site geometry.

Q: What is the detection range? A: The listed detection range is 200–1000 m under reference conditions of visibility greater than 10 km and RCS greater than 0.01 m². Real-world detection performance may vary.

Q: What is the intercept distance? A: The listed intercept distance is 200–600 m under reference conditions of visibility greater than 10 km and RCS greater than 0.01 m². Intercept use requires lawful authorization, operator training and laser-safety procedures.

Q: What is the laser output power? A: The laser output power is listed as ≤1.4 kW. This is a restricted laser-interception function and must be operated only by authorized trained users under applicable safety and legal requirements.

Q: What is the intercept time? A: The listed intercept time is ≤20 seconds. Actual intercept time depends on target behavior, distance, visibility, operator workflow, system configuration and safety constraints.

• Q: What is the tracking accuracy?
• A: HD-2 tracking accuracy is listed as <10 μrad RMS, supporting high-precision stabilized tracking of consumer drone targets under suitable conditions.

• Q: What is the detection angle?
• A: The detection angle is listed as azimuth -175° to 175° and pitch -10° to 60°, providing wide-angle coverage for portable low-altitude security deployment.

• Q: How fast can HD-2 be deployed?
• A: HD-2 can be deployed in under 1 minute, making it suitable for rapid-response field security operations when used by trained authorized operators.

Q: Can one person operate the system? A: Yes, HD-2 is designed for single-person portable deployment and control through a visual interface. Operators still require proper training, safety procedures and authorization.

Q: What does the control terminal show? A: The control terminal can show target status, battery status, intercepted image, distance and system information. Terminal options include 9″ and 15″ screen configurations depending on package.

• Q: What communication method is used with the terminal?
• A: The control terminal supports wired bidirectional communication. Final control layout depends on selected configuration and deployment mode.

Q: Does HD-2 support automatic unmanned control? A: Optional automatic unmanned control is available depending on configuration and approval. Use of automated functions must follow applicable safety, legal and operational requirements.

Q: What deployment modes are supported? A: HD-2 supports single-person portable tripod deployment, fixed installation and vehicle-mounted configuration. The best deployment mode depends on site layout, risk level, power availability and operating permissions.

• Q: What is the weight of the system?
• A: The listed system weight is under 45 kg, placing it in a portable professional field-deployment class.

• Q: What is the battery replacement time?
• A: Battery replacement is listed as under 30 seconds, supporting fast field turnaround when spare batteries and approved procedures are available.

• Q: What is the laser emission time?
• A: The laser emission time is listed as 240 seconds. Actual operational use must comply with safety limits, site approvals and authorized procedures.

• Q: What angular performance does the stabilized head support?
• A: The system lists angular acceleration greater than 60°/s² and maximum angular velocity greater than 60°/s, supporting rapid tracking response.

• Q: What temperature range does HD-2 support?
• A: The standard operating temperature range is -20°C to +55°C. A special configuration may support -40°C to +55°C depending on package.

Q: Where can HD-2 be used? A: HD-2 is suitable for authorized deployment at energy facilities, power stations, factories, airports, train stations, stadiums, concerts, private estates, high-end communities and intelligent city low-altitude security networks.

Q: Is HD-2 an RF jammer? A: HD-2 is primarily described as a detection, identification, tracking and laser-interception system. It should not be treated as an RF jammer unless a separate RF mitigation module is specified in a custom package.

Q: Who can purchase HD-2? A: Suitable buyers include government agencies, defence organizations, law-enforcement bodies, airport security teams, energy facility operators, critical infrastructure security teams, approved security agencies and licensed C-UAS integrators.

Q: Is HD-2 available for civilian hobby use? A: No. HD-2 is a restricted counter-UAS and laser-interception system and is not intended for hobby, recreational, private or unauthorized use. Procurement and operation require lawful authorization.

Q: What compliance requirements apply? A: HD-2 may require KYC, end-use documentation, site approval, laser-safety controls, aviation permissions, operator training, risk assessment and other applicable security/regulatory approvals.

Q: Can FlySpark customize the HD-2? A: Yes, FlySpark can support custom configurations including portable tripod deployment, fixed installation, vehicle-mounted setup, operator terminal options, workflow integration and site-specific deployment planning.

Q: What maintenance is required? A: Maintenance should include inspection of the gimbal head, optical system, laser module, tripod, cables, power system, batteries, control terminal, connectors and software status. Scheduled professional maintenance is recommended.

Q: What warranty is included? A: Warranty support generally covers manufacturing defects under approved use and normal operating conditions. Damage from unauthorized operation, unsafe laser use, incorrect installation, physical impact, water ingress, tampering or unapproved modification may not be covered.
