Swiwin Turbine SW600PRO 60Kg Thrust Jet Engine

Swiwin Turbine SW600PRO 60Kg Thrust Jet Engine

The Swiwin SW600PRO is a high-thrust miniature turbojet engine designed for advanced RC jet aircraft, heavy turbine model aircraft, UAV propulsion research, aerospace test platforms and professional turbine integration projects. Delivering 60kg / 600N thrust, the SW600PRO is built for pilots and integrators who require serious power, fast turbine response, intelligent ECU control and reliable operation in demanding setups.

KEY FEATURES & BENEFITS:

• High-Thrust 60Kg Turbine Platform:
• • 60kg / 600N thrust class turbojet engine
• • 25,000–72,000 RPM operating speed range
• • 25,000 RPM idle reference
• • Compact high-power turbine package
• • 6600g engine weight reference
• • 177mm diameter and 452mm length reference
• • Suitable for heavy RC jets, turbine UAV research and controlled propulsion test platforms

• Advanced ECU V5 Control:
• • ECU V5 intelligent turbine control system
• • Brushless starter support for stable starting
• • Telemetry support for real-time turbine data monitoring
• • Auto-start turbine operation
• • Auto-restart feature positioning
• • Fault diagnosis and data storage support
• • Compatible sensor-data management for fuel, ignition timing and brushless motor control

• Professional Turbine Integration:
• • Aviation kerosene fuel compatibility
• • 3%–5% lubrication reference
• • Rated exhaust maximum temperature of 750°C
• • Fuel consumption reference of ≤1735g/min
• • 25-hour maintenance cycle
• • Designed for high response time, reliability and demanding turbine applications
• • Installation and operation must be handled by trained turbine operators only

APPLICATIONS: Large RC jet aircraft, heavy turbine model aircraft, UAV turbine propulsion research, aerospace propulsion test platforms, high-thrust turbine demonstrations, jet trainer model projects, professional RC turbine workshops, engineering college propulsion labs, turbine engine evaluation platforms, aeromodelling clubs, advanced aircraft power-system integration, controlled turbine testing and maintenance training.

FREQUENTLY ASKED QUESTIONS:

Q: What is the Swiwin SW600PRO turbine? A: The Swiwin SW600PRO is a high-thrust miniature turbojet turbine engine for large RC jet aircraft, heavy turbine model aircraft, UAV propulsion research and controlled propulsion test platforms.

Q: What is the price of the Swiwin SW600PRO turbine? A: The listed import price is 2,98,000 ₹ for the Swiwin SW600PRO 60Kg Turbine Standard Package. Final pricing may vary if installation support, telemetry setup, fuel-system planning, workshop support or propulsion test support is added.

• Q: What thrust does the Swiwin SW600PRO produce?
• A: The listed thrust is 60kg / 600N.

• Q: What is the RPM range?
• A: The listed speed range is 25,000–72,000 RPM.

• Q: What is the idle RPM?
• A: The listed idle RPM is 25,000 RPM.

• Q: What are the dimensions of the SW600PRO?
• A: The listed turbine diameter is 177mm and the listed length is 452mm.

• Q: What is the engine weight of the SW600PRO?
• A: The listed engine weight is 6600g.

• Q: What is the total weight including accessories?
• A: The technical sheet reference lists total weight including accessories as 8630g.

• Q: What is the ECU weight?
• A: The listed ECU weight is 910g.

• Q: What is the rated exhaust temperature?
• A: The listed rated exhaust maximum temperature is 750°C. Turbine exhaust is extremely hot and requires strict safety management.

• Q: What fuel does the Swiwin SW600PRO use?
• A: The listed fuel is aviation kerosene. Fuel quality and oil percentage should follow the turbine manual and local fuel availability.

• Q: What lubrication percentage is required?
• A: The listed lubrication reference is 3%–5%. Use suitable turbine oil according to manual guidance.

• Q: What is the fuel consumption?
• A: The listed fuel consumption reference is ≤1735g/min. Actual fuel consumption depends on RPM, throttle profile, air density and operating conditions.

• Q: What ECU does the SW600PRO use?
• A: The SW600PRO is listed with ECU V5.

• Q: Does the SW600PRO have auto-start?
• A: Yes, the SW600PRO supports one-button electronic start / ECU-controlled auto-start operation.

• Q: Does the SW600PRO have auto-restart?
• A: Yes, the Aeromodellingtutor product page highlights auto-restart functionality.

• Q: Does it include telemetry?
• A: Yes, the product page highlights telemetry support so relevant engine information can be monitored through compatible radio/telemetry systems.

• Q: What starter system does it use?
• A: The product page highlights a brushless starter. Technical parameters also reference starter ejection and starter run voltage values.

• Q: What is the maintenance interval?
• A: The listed maintenance cycle is 25 hours.

• Q: What is the operating temperature range?
• A: The technical reference lists an operating temperature range of -40°C to +50°C.

• Q: What supply voltage is required?
• A: The technical reference lists supply voltage as 18V–32V.

Q: Is this turbine suitable for beginners? A: No. The SW600PRO is an advanced high-thrust turbine engine intended for trained turbine operators, experienced RC jet pilots, UAV propulsion engineers and professional workshops.

• Q: What aircraft is the SW600PRO suitable for?
• A: It is suitable for compatible large RC jet aircraft, heavy turbine model aircraft, turbine UAV research platforms and controlled propulsion test platforms.

Q: Is the SW600PRO suitable for UAV prototypes? A: It may be evaluated in lawful UAV propulsion research or prototype projects only if the airframe, fuel system, ECU, thermal safety, failsafe design, field safety and aviation compliance requirements are professionally engineered.

Q: What else is required for installation? A: Typical required items include compatible aircraft or test-frame mount, turbine fuel tank, fuel tubing, suitable battery, receiver interface, ECU/GSU setup, fuel filter, fuel valve, heat shielding, fire extinguisher, ground support tools and safe test-area equipment.

Q: What safety precautions are important? A: Operators must follow turbine fire safety, fuel safety, hot-exhaust safety, intake safety, hearing protection, failsafe checks, controlled startup, controlled shutdown and field rules. Never operate the turbine near loose objects, people, dry grass or flammable materials.

• Q: Why is FOD prevention important?
• A: Foreign object debris can damage the compressor and turbine section. Keep the intake area clean and secure all loose items before starting the turbine.

Q: What maintenance is required? A: Maintenance should include checking fuel filters, fuel lines, ECU data, pump function, starter function, battery health, turbine mounts, intake cleanliness, exhaust area, telemetry readings and scheduled service at the listed maintenance interval.

Q: What warranty is included? A: Warranty support generally covers manufacturing defects under approved use and normal operating conditions. Damage from FOD ingestion, bad fuel, incorrect oil mix, overheating, crash impact, improper ECU setup, fuel-system contamination, water exposure, unauthorized modification or unsafe operation may not be covered.
