FlySpark Guardian-X11 Military Grade 11-Band 200W Anti-Drone Jamming System | 2200W Total RF Output | 400MHz–6GHz
Guardian-X11 2200W anti-drone RF jamming system with 11×200W bands, 400MHz–6GHz coverage, high-gain antennas and 1.8km tested range.
Base Price
₹33,90,000
Excl. GST · Final pricing subject to configuration & quantity
Defense & export systems — request a quote for pricing, lead time, and end-user documentation.
Request QuoteWhatsApp ConnectView 11-Band Frequency ListQty1
Military-grade quality assured
Export compliant documentation
24/7 engineering support
System Tags
flysparkguardian-x11-2200wanti-drone-jamming-system200w-drone-jammer2200w-drone-jammer11-band-drone-jammermilitary-grade-drone-jammeruav-jammerrf-jammercounter-uav-systemc-uas-system400mhz-6ghz-jammer
Mission Configurations
Configuration(9)
Select your operational configuration. Pricing may vary — request a formal quote for deployment quantities.
Configuration Matrix
Compare All Variants
Side-by-side specs from product_variants — click a column to select
| Parameter | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Unit Price (excl. GST) | ₹33,90,000 | ₹33,90,000 | ₹33,90,000 | ₹33,90,000 | ₹33,90,000 | ₹33,90,000 | ₹33,90,000 | ₹33,90,000 | ₹33,90,000 |
| Stock | 10 units | 10 units | 10 units | 10 units | 10 units | 10 units | 10 units | 10 units | 10 units |
| SKU | FSP-GUARDIAN-X11-2200W-400M-6G | FSP-GUARDIAN-X11-2200W-VEHICLE | FSP-GUARDIAN-X11-2200W-ROOFTOP-TOWER | FSP-GUARDIAN-X11-2200W-BORDER-STRATEGIC | FSP-GUARDIAN-X11-2200W-CRITICAL-INFRA | FSP-GUARDIAN-X11-2200W-VIP-EVENT | FSP-GUARDIAN-X11-2200W-CUSTOM-BANDS | FSP-GUARDIAN-X11-2200W-TRAINING-COMPLIANCE | FSP-GUARDIAN-X11-2200W-INSTALL-COMMISSION |
Shared RF channel map · 400 MHz – 6 GHz
11-Band Frequency List
All Guardian-X11 models use this same 11-band plan. Center frequency, operating range and target links are listed below. RF power per band depends on the model you select — wattage is not shown here.
11 channels
- 01
450 MHz
Center
450 MHz
Operating range
350–550 MHz
Primary targets
UHF, IoT, Smart Home, Long-Range Drones
- 02
900 MHz
Center
900 MHz
Operating range
800–1000 MHz
Primary targets
FPV Drone Links, ISM, Older Cellular
- 03
1200 MHz
Center
1200 MHz
Operating range
1100–1300 MHz
Primary targets
GNSS L2/L5, GLONASS (Backup Navigation)
- 04
1400 MHz
Center
1400 MHz
Operating range
1300–1500 MHz
Primary targets
Satellite Communications, L-Band
- 05
1600 MHz
Center
1600 MHz
Operating range
1500–1700 MHz
Primary targets
Primary GPS L1 (Core Navigation at 1575 MHz)
- 06
2400 MHz
Center
2400 MHz
Operating range
2300–2500 MHz
Primary targets
DJI Drone Control, Bluetooth, 2.4GHz Wi-Fi
- 07
3300 MHz
Center
3300 MHz
Operating range
3200–3400 MHz
Primary targets
5G C-Band (Low)
- 08
3900 MHz
Center
3900 MHz
Operating range
3800–4000 MHz
Primary targets
5G High-Speed Broadband
- 09
4900 MHz
Center
4900 MHz
Operating range
4800–5000 MHz
Primary targets
Custom/Military Drone Links
- 10
5200 MHz
Center
5200 MHz
Operating range
5100–5300 MHz
Primary targets
5GHz Wi-Fi (Lower Channels)
- 11
5800 MHz
Center
5800 MHz
Operating range
5700–5900 MHz
Primary targets
FPV Video Downlinks, 5.8GHz Wi-Fi
11 independent bands · same frequency plan across Guardian-X11 models · power is model-specific
Intelligence Brief
Mission Overview
FlySpark Guardian-X11 Military Grade 11-Band 200W Anti-Drone Jamming System | 2200W Total RF Output
The FlySpark Guardian-X11 2200W is a high-power military-grade anti-drone RF jamming system engineered for authorized defense, border security, airport protection, critical infrastructure security, government facility protection, VIP security and strategic counter-UAS deployments. Powered by 11 independent 200W RF modules, the system delivers approximately 2200W combined RF output across configured 400MHz–6GHz drone communication, telemetry, navigation-related and video transmission bands.
Built for demanding field environments, the Guardian-X11 2200W features military-grade construction, industrial cooling, high-gain antenna support, continuous-duty operation and plug-and-play deployment architecture.
KEY FEATURES & BENEFITS:
- High-Power 2200W RF Output:
- • 11 independent RF channels with 200W output per channel
- • Approx. 2200W combined RF output
- • 400MHz–6GHz configured frequency coverage
- • Stronger coverage than 550W and 1100W Guardian-X11 variants
- Real-World Tested Coverage:
- • Omnidirectional antenna coverage: approx. 1.0–1.3km
- • Directional antenna coverage: approx. 1.5–1.8km
- • Coverage depends on antenna configuration, installation height, terrain and target drone system
IMPORTANT RESTRICTED-USE NOTICE: This product includes high-power RF jamming capability and is restricted to legally authorized users only. KYC, end-use verification, WPC/DoT/spectrum permissions and trained operators may be required.
FREQUENTLY ASKED QUESTIONS:
- Q: What is the FlySpark Guardian-X11 2200W?
- A: A high-power military-grade 11-band anti-drone RF jamming system with eleven independent 200W RF modules and approximately 2200W total combined RF output.
- Q: What is the price of the Guardian-X11 2200W?
- A: The listed price is ₹33,90,000 for the standard Guardian-X11 2200W package.
- Q: What is the total RF output power?
- A: Approximately 2200W combined power from 11 × 200W bands.
- Q: What is the omnidirectional coverage?
- A: Real-world tested omnidirectional coverage is approximately 1.0–1.3km.
- Q: What is the directional coverage?
- A: Real-world tested directional coverage is approximately 1.5–1.8km.
- Q: How is this different from the 1100W Guardian-X11?
- A: The 2200W version uses 200W per band for higher total RF output and greater field-tested coverage.
- Q: Is it suitable for vehicle mounting?
- A: Yes. It is vehicle-mount ready for authorized mobile security and tactical operations.
- Q: What is included in the package?
- A: Main unit, high-gain antenna set, mounting hardware, cooling system, power interface assembly and documentation.
- Q: Is Guardian-X11 2200W made in India?
- A: Yes. Designed and manufactured by FlySpark / AnuShakti Infotech Pvt. Ltd. in India.
- Q: What warranty is included?
- A: 1 Year manufacturing defect support under approved installation and lawful operation.
Technical Data Sheet
System Specifications
34 parameters across 4 categories
General
21 fieldsProduct Type
High-power counter-UAV RF defense platform
Model
FlySpark Guardian-X11 2200W
System Class
11-band high-power anti-drone jamming platform
Total RF Output
Approx. 2200W combined RF output
RF Module Configuration
11 independent 200W RF jamming modules
Output Per Band
200W per band
Frequency Coverage
400MHz–6GHz configured coverage range
Channel Count
11 independent RF channels
Deployment Type
Vehicle-mounted, rooftop-mounted, tower-mounted, fixed-site and mobile deployment support
Build Origin
Made in India
Manufacturer / Supplier
FlySpark / AnuShakti Infotech Pvt. Ltd.
Omnidirectional Antennas
Approx. 1.0–1.3km field-tested reference
Directional Antennas
Approx. 1.5–1.8km field-tested reference
Coverage Depends On
Antenna configuration, gain, installation height, terrain, RF interference, weather and target drone system
Deployment Options
Vehicle-mounted, rooftop, tower, border posts, airports, critical infrastructure, government facilities, VIP security
System Features
2200W combined output, wide-spectrum 400MHz–6GHz, industrial cooling, military-grade construction, plug-and-play, 24/7 operation
Construction
Rugged military-grade enclosure, industrial-grade hardware, heavy-duty field deployment design
Package Contents
Main unit, high-gain antenna set, mounting hardware, cooling system, power interface assembly, documentation
Serviceability
Modular RF architecture, custom band configuration support, low-maintenance design
Compliance Status
Restricted high-power RF jamming equipment — authorized buyers only
Warranty
1 Year manufacturing defect support under approved installation and lawful operation
