Product Type: Hybrid VTOL Fixed-Wing UAV Platform
Airframe Material: Aerospace-grade carbon fiber composite
Length: 2020 mm
Front Wingspan: 2820 mm
Rear Wingspan: 3744 mm
Height: 696 mm
Engine Type: Gasoline EFI engine
Fuel Type: Hybrid fuel
Fuel Tank Capacity: 13 L
Payload Capacity: Up to 18 kg including fuel and mission payload
Maximum Takeoff Weight: 40 kg
Cruise Speed: 25 m/s
Fuel Consumption: 0.96 L/h
Flight Time: Up to 15 hours with 5 kg payload
Maximum Climb Rate: 4–6 m/s
Maximum Takeoff Altitude: 3500 m
Service Ceiling: 5850 m
Wind Resistance: Level 5 for takeoff/landing, Level 6 in flight
Operating Temperature: -20°C to +50°C
Protection Rating: IPX4
Takeoff / Landing Method: Vertical takeoff and landing.

• Hybrid VTOL fixed-wing UAV platform
• Vertical takeoff and landing without runway requirement
• Long-endurance flight performance up to 15 hours with 5 kg payload
• Heavy payload support up to 18 kg including fuel and mission payload
• Aerospace-grade carbon fiber composite airframe
• Tandem-wing aerodynamic design for improved efficiency
• Dual payload compartments for flexible mission equipment setup
• Gasoline EFI engine system for long-range operation
• IPX4 protection rating for outdoor field use
• Wind resistance up to Level 6 during flight
• Five control surfaces for improved safety redundancy
• Suitable for survey, mapping, inspection, monitoring, and emergency response.

Product Type: Hybrid VTOL Fixed-Wing UAV Platform
Airframe Material: Aerospace-grade carbon fiber composite
Length: 2020 mm
Front Wingspan: 2820 mm
Rear Wingspan: 3744 mm
Height: 696 mm
Engine Type: Gasoline EFI engine
Fuel Type: Hybrid fuel
Fuel Tank Capacity: 13 L
Payload Capacity: Up to 18 kg including fuel and mission payload
Maximum Takeoff Weight: 40 kg
Cruise Speed: 25 m/s
Fuel Consumption: 0.96 L/h
Flight Time: Up to 15 hours with 5 kg payload
Maximum Climb Rate: 4–6 m/s
Maximum Takeoff Altitude: 3500 m
Service Ceiling: 5850 m
Wind Resistance: Level 5 for takeoff/landing, Level 6 in flight
Operating Temperature: -20°C to +50°C
Protection Rating: IPX4
Takeoff / Landing Method: Vertical takeoff and landing.

Airframe Only:
Carbon fiber airframe without power or control systems. Suitable for advanced integrators and UAV development teams.

PNP Kit:
Airframe with propulsion system for easier installation and setup.

RTF Kit:
Fully assembled and integrated ready-to-fly configuration. Availability depends on region and compliance requirements.

• Large-area aerial survey
• High-accuracy mapping
• Infrastructure inspection
• Environmental monitoring
• Emergency response support
• Disaster assessment
• Agriculture and land monitoring
• Industrial observation
• Research and development
• Long-range UAV field operations
• Perimeter and asset monitoring where legally permitted
