The FlySpark SkyStream-P33 1.4GHz Long-Range Video & Data Transmission System is a professional wireless communication solution designed for UAVs, VTOL drones, fixed-wing aircraft, industrial monitoring systems, inspection platforms, and ground control station integration.

Built on industrial-grade FPGA and wireless transceiver technology, the SkyStream-P33 provides a unified link for video transmission, telemetry data, command communication, and control signal support. It is suitable for professional drone operators who need stable air-to-ground communication for inspection, monitoring, mapping, survey, firefighting support, emergency response, and industrial UAV operations.

The system operates in the 1350–1470MHz frequency range and supports 2T2R wireless transmission. With 2W / 33dBm transmit power, it supports air-to-ground visibility of more than 30km with omni antennas and more than 60km with directional antennas depending on installation, antenna setup, terrain, and operating environment.

The FlySpark SkyStream-P33 includes adaptive channel selection, real-time interference detection, adaptive channel code rate, automatic retransmission, automatic power control, and adaptive modulation. These features help improve anti-interference performance, reduce multipath issues, and maintain reliable low-latency communication during UAV operation.

With dual network ports and multiple serial interfaces, the SkyStream-P33 can connect with IP cameras, flight controllers, payload systems, telemetry devices, and other UAV communication equipment.

Key Features:

• 1.4GHz long-range UAV video and data transmission system
• Unified solution for video, command, control, and telemetry communication
• Air-to-ground range over 30km with omni antennas
• Air-to-ground range over 60km with directional antennas
• Industrial-grade FPGA and transceiver technology
• Adaptive Channel Selection for improved communication reliability
• Real-time interference detection with anti-interference algorithm processing
• Automatic Power Control for optimized transmission performance
• Adaptive modulation based on channel conditions
• Automatic retransmission for improved data reliability
• High reliability, excellent stability, and low latency
• Dual network ports and multiple serial ports
• Suitable for UAVs, VTOL drones, fixed-wing platforms, and industrial monitoring systems

Specifications:

Product Type: Long-Range UAV Video & Data Transmission System
Brand: FlySpark
Model Name: SkyStream-P33
Working Frequency: 1350–1470MHz
Custom Frequency Support: 2.4GHz and other frequencies available depending on project requirement
Wireless Channel: 2T2R
Transmission Power: 33dBm / 2W
Transmission Distance with Omni Antennas: 30km+
Transmission Distance with Directional Antennas: 60km+
Channel Bandwidth: 10MHz
Modulation Mode: QPSK / 16QAM
Receiving Sensitivity: -99dBm @ 10MHz @ QPSK 1/3
Data Rate: Up to 17Mbps @ 16QAM 3/4
Transmission Delay: Approx. 10ms
RF Interface: SMA × 2
Equipment Interface: Network Port × 2, TTL / RS232 × 2, 422, SBUS
Air Unit Power Consumption: ≤25W
Ground Unit Power Consumption: ≤10W
Working Voltage: DC 9–26V
Typical Voltage: 12V @ 3A
Dimensions: 148 × 65 × 17mm
Weight: Approx. 208g
Operating Temperature: -40°C to +75°C

Package Includes:

• FlySpark SkyStream-P33 Bidirectional Wireless Link Unit × 2
• 1.4GHz Airborne Antenna × 2
• 1.4GHz Ground Antenna Set × 2
• Power Connection Cables
• J30J Cables
• Serial Communication Cables
• Antenna Extension Cables depending on package

Applications:

• UAV video and data transmission
• VTOL drone ground station communication
• Fixed-wing UAV telemetry and payload data link
• Industrial inspection drone communication
• Aerial mapping and survey operations
• Firefighting support drone systems
• Emergency response communication support
• Remote monitoring and field operation
• Infrastructure inspection
• Environmental monitoring
• Research and development UAV projects
• Professional ground control station integration

The FlySpark SkyStream-P33 is suitable for UAV manufacturers, drone integrators, mapping teams, inspection agencies, emergency response teams, industrial monitoring operators, and professional drone users who need a reliable long-range wireless video and data communication system.
