FlySpark AGT-3D-RD5000X Ku-Band 3D Radar
The AGT-3D-RD5000X is a portable, high-accuracy Ku-band (10.4–10.6 GHz) 3D radar for
low-altitude and perimeter security. With full 360° coverage, fast rotation and IP67
weather protection, it delivers reliable detection and tracking for drones, vehicles and personnel.
Key Benefits
- 360° situational awareness with −5° to 30° elevation coverage; height ≥800 m
- Accurate tracking: az/el ≤0.4° (RMS), range ≤5 m (RMS); blind area ≤50 m
- Fast updates: 180°/s antenna rotation; typical update rate ≈1.2 s
- High capacity: tracks ≥150 targets from 0.4–100 m/s radial velocity
- Rugged & efficient: IP67, −40 °C to +55 °C, ≤200 W, DC48 V or AC220 V
- Easy deployment: compact 425×300×48 mm head; tripod or fixed-site mounting
Performance (typical)
- Detection range: ≥5 km (Phantom-class UAV), ≥8 km (personnel), ≥10 km (vehicle);
extended configuration 7–20 km (environment & RCS dependent) - Coverage: Azimuth 360°, Elevation −5° to 30°
- Target capacity: ≥150
Technical Specifications
| Operating frequency | 10.4–10.6 GHz (Ku-band) |
|---|---|
| Frequency hopping modes | 4 or 8 (model/firmware dependent) |
| Angle accuracy | Azimuth ≤0.4° (RMS), Elevation ≤0.4° (RMS) |
| Range accuracy | ≤5 m (RMS) |
| Detection speed range | 0.4–100 m/s |
| Antenna rotation speed | 180°/s |
| Dimensions (H×W×D) | 425 × 300 × 48 mm |
| Ingress protection | IP67 |
| Power supply | DC 48 V or AC 220 V |
| Power consumption | ≤200 W |
| Operating temperature | −40 °C ~ +55 °C |
Optional Integrated EO Module
Optional day camera (H.265, 2–3 MP, f/2.0, 10 mm lens), human motion tracking, face detection,
two-way audio, pan-tilt, alarm I/O; cloud / memory card / micro-SD storage.
Use Cases
- Anti-drone / low-altitude s
FlySpark AGT-3D-RD5000X is a compact Ku-band 3D surveillance radar for low-altitude/anti-drone missions. Operating at 10.4–10.6 GHz, it delivers 360° coverage, 0.4° (RMS) az/el angle accuracy, ≤5 m ranging accuracy, 180°/s rotation and IP67 protection. Typical detection: ≥5 km (Phantom-class UAV), ≥8 km personnel, ≥10 km vehicles; extended variant up to 7–20 km (site/target dependent). Tracks ≥150 targets, handles 0.4–100 m/s speeds, and updates every ~1.2 s. Dual power DC 48 V or AC 220 V, ≤200 W. Portable tripod or fixed mount. Distributed & supported by FlySpark (India) for authorized users.
